The LCT620AD Clamp-On Base Desktop Monitor Mounts feature two attractive height adjustable articulating arms that provide perfect ergonomics with optimum monitor positioning for virtually all users. The clamp-on mounting base allows for limitless mounting options on any desktop or countertop surface between ½" to 2" (12 to 55mm) thick.
- Articulating arms allow monitors to be adjusted to the perfect ergonomic position to help reduce eye, back and neck strain
- Accommodates different monitor weights ranging from 8.4 to 17.8lb (3.8 to 8.1kg)
- Smooth and effortless arm movement provided by bushings at all pivot points
- Compatible with VESA® 75 x 75mm and 100 x 100mm mounting patterns
- Monitors can be positioned anywhere from 2.00" to 20.50" (50 to 502mm) above the desktop surface measured at the center of the adaptor
- Both style mounting bases accommodate a desktop or counter thickness of 0.2" to 2.2" (5-55mm) thick
- Expertly finished polished aluminum arm and black base with chrome pole
- Integrated cable management provides clean, professional installation finish
Peerless-AV LCT620AD Specs
General
Supported Screen Sizes |
Up to 29" / 73.7 cm
|
Number of Displays Supported |
2, Side-by-Side
|
Load Capacity |
17.8 lb / 8.1 kg (Per Arm)
|
Mounting-Hole Pattern |
75 x 75 to 100 x 100 mm
|
Orientation |
Landscape, Portrait
|
Desk Clamp Compatibility |
0.2 to 2.2" / 0.5 to 5.6 cm
|
Adjustments
Rotation Adjustment |
360°
|
Tilt Adjustment |
125° (-90 to 45°)
|
Swivel Adjustment |
180°
|
Height Adjustment |
12.6" / 32.0 cm
|
Max Arm Extension Length |
22" / 55.9 cm
|
Physical
Certifications |
TAA *as per Manufacturer
|
Weight |
19.8 lb / 9 kg
|
Packaging Info
Package Weight |
20.285 lb
|
Box Dimensions (LxWxH) |
18.3 x 16.6 x 10.4"
|
